Katool 11K FLOOR PLATE 2-POST LIFT 4.0 HP MOTOR, LOW PROFILE ARMS
$1,999.00
SKU
KAT*KT-H115Z
This Katool H115Z 11,000lbs two-post lift arrives in a base-plate design that simplifies installation and unloading.
Designed for serious professionals and auto enthusiasts alike, the H115Z combines brute strength with refined engineering. With a whopping 11,000lb lifting capacity, it's built to raise everything from light trucks to heavier SUVs—without breaking a sweat. Dual hydraulic chain-drive cylinders deliver smooth, reliable lifting power, while the top-tier hydraulic system (220V/60Hz) ensures consistent performance day in and day out.
Specifications
| Lifting Capacity | 11,000 lbs (5,000 KG) |
| Max. Lifting Height | 70.8" (1800mm) |
| Minimum Height | 3.9" (100mm) |
| Overall Height | 110.9" (2818mm) |
| Overall Width | 140.4" (3565mm) |
| Outside Column Width | 124.8" (3170mm) |
| Inside Column Width | 110.2" (2800mm) |
| Drive-Thru Clearance | 98.4" (2500mm) |
| Front Arm Reach (Min) | 29.5" (750mm) – 2 stages |
| Front Arm Reach (Max) | 46" (1170mm) – 2 stages |
| Rear Arm Reach (Min) | 35.4" (900mm) – 2 stages |
| Rear Arm Reach (Max) | 58.2" (1480mm) – 2 stages |
| Motor | 220VAC / 60Hz / 1PH / 2.2KW |
| Net Weight | 570 KG |
| Design | Base Plate |
| Safety Lock Release | Manual (Dual Side) |
| Hydraulic System | Top-Level with Dual Chain-Drive Cylinders |
| Rubber Door Guards | Included |
| Extension Adapters | Screw-on Pads with +100mm Adaptors |
| Certification | CE Approved (115% dynamic / 150% static test) |
